0.5 Ton Electric Utility Golf Cart

Key Features:

✔ Electric Powertrain – Quiet, zero-emission operation with low maintenance.
✔ 0.5 Ton (1,000 lb) Payload – Strong hauling capacity for a golf cart.
✔ Durable Utility Bed – Steel or reinforced cargo area for heavy loads.
✔ Reliable Performance – Long-lasting batteries (lead-acid or lithium, if applicable).
✔ Compact & Maneuverable – Easy to drive in tight spaces (golf courses, farms, warehouses).
✔ Optional Features – Lights, windshield, dump bed, or tow hitch (if equipped).

Ideal For:

• Landscapers & Contractors
• Golf Course Maintenance
• Farm & Ranch Use
• Warehouse / Industrial Transport
• Resort & Campus Utility Vehicle


  Capacity	2 people	Vehicle weight (including battery)	635KG
  length x width x height	3350*1220*1930mm	Driving speed	25-30km/h (adjustable)
  Driving range	70-90km	Safe grade	≤15%
  wheelbase	2570mm	Minimum turning radius	5m
  Front track	880mm	Minimum ground clearance	122mm
  rear track	998mm	Braking distance	3.5m
  Controller	Overview	Enpower AC intelligent controller, strong climbing ability, anti-rollback on slopes, speed limitable downhill, braking or reverse energy feedback control, to improve the driving mileage of the vehicle
  	Voltage (DC/V)	48V
  	Maximum output current (AC/A)	400
  	Rated output current (AC/A)	130
  	Working ambient temperature range	-20℃—-55℃
  	Protection class	IP67
  	effectiveness	98%
  	cooling method	Free cooling
  	Motor control method	Vector control with speed sensor
  	communication method	CAN communication
  Motor	Overview	Asynchronous AC motor, high efficiency and energy saving, stepless speed regulation, fully enclosed aluminum shellSeal, good heat dissipation, high output efficiency, strong overload/climbing ability. Maintenance free.
  	Voltage and power (V/kw)	48V/5kw
  	Rated current (A)	116
  	Rated speed (r/min)	3000
  	Maximum speed (r/min)	4500
  	work schedule	S2-60min
  	Protection class	IP54
  	Insulation class	H
  	cooling method	Free cooling
  	Efficiency (100% load)	85
  Battery	Overview	Torch brand, add liquid, deep cycle large capacity lead-acid battery, Long service life and superior discharge performance at high current. (Optional free maintenance battery)
  	model	4-DG-140 (optional 4-EVF-150)
  	capacity	140Ah (5hr) 8V/pcs, 6 pcs totally
  	Battery pack voltage and capacity (V/Ah)	48v/140Ah*6 pcs
  	Storage power (degree: kw/h)	48v*140Ah=6.72
  Charger	Computer intelligent car charger, full charge time is about 6-8 hours, with automatic power off protection after full chargeProtection function. Charge input voltage 220V, output 48V/25A, protection grade: IP67.
  DC voltage converter	High power DC converter, 48V/12V-300W.
  Windshield	Folded Windshield(organic glass)
  Canopy	Injection molding of automotive engineering materials is light in weight and not easy to fade.
  Body	Injection molding of PP material for automobiles. The exterior parts of the whole vehicle are made of fully injection-molded material, modular structure design, and can be divided intoChip replacement saves maintenance costs.
  Bracket	Professionally designed and welded by mold opening, the surface is sprayed, the shape is simple, the quality is high, and it is anti-rust.
  Seat	Foamed sponge high-grade imitation leather seat, high resilience and not easy to deform.
  Floor	Non-slip, quiet, easy to clean, corrosion-resistant, high-strength wear-resistant floor glue.
  Dashboard	Special PP material injection molding instrument panel. Combination instrument, far and near light switch, turn signal switch, electric lock switch,Front and rear gear switches.
  Lights and Signals	Integrated LED daytime running lights, running water turn signals, horn, reversing buzzer, energy saving and convenientdisassembly.
  Steering system	Rack and pinion steering system with automatic backlash compensation function.
  Braking method	Composite pedal parking (optional electromagnetic parking)
  Braking System	rear drum brake
  Front and rear suspension system	Front Independent Suspension; Rear Integral Axle
  Tire wheel	Golf car tires aluminum rim 205/50-10
